Silent install

A silent install is the installation of a software program that requires no user interaction. It is a convenient way to streamline the installation process of a desktop application like LEAPWORK Studio, LEAPWORK Controller or the LEAPWORK Agent.

The LEAPWORK installer is based on MSI, and can be used from the command-line like this:

msiexec.exe [MSI COMMAND] [MSI INSTALLER FILE PATH] [MSI COMMAND OPTIONS] [INSTALLER PACKAGE PARAMETERS]

  • [MSI COMMAND]
    • /i -- installation;
    • /u -- uninstallation.
  • [MSI INSTALLER FILE PATH]:
    • a (quoted if contains spaces) path to the installer file;
  • [MSI COMMAND OPTIONS]
    • /qn -- queit/no UI installation;
    • /norestart -- no restart;
    • /forcerestart -- forced restart;
    • /l*v -- enables verbose logging;
  • [INSTALLER PACKAGE PARAMETERS]:An optional list of the package parameters. It may contain a list of required "features" and other parameters like ports, shortcuts, paths & etc. Any parameter's value should be quoted if it contains spaces.
    • List of features
      • AgentFeature -- the agent;
      • ControllerFeature -- the controller;
      • StudioFeature -- the studio.
    • Properties
      • ADDLOCAL -- a comma separated list of features to be installed. Default: all features;
      • LEAPWORK_AGENT_PORT -- a TCP port to be used by the Agent. Possible values: any valid TCP port. Default: 6777;
      • LEAPWORK_AGENT_FIREWALLEXCEPTION -- indicates whether to create a rule for the Agent's port in the firewall. Possible values: true/false. Default: true;
      • LEAPWORK_AGENT_PASSWORD -- a password that secures connection to the Agent. Possible values: any string. Default: empty string;
      • LEAPWORK_CONTROLLER_PORT -- a TCP port to be used by the Controller. Possible values: any valid TCP port. Default 9000.
      • LEAPWORK_CONTROLLER_API_PORT – a HTTP port for Public REST API endpoints. Possible values. Default 9001.
      • LEAPWORK_CONTROLLER_PASSWORD – initial password for LEAPWORK administrator by default called as “admin”.
      • LEAPWORK_CONTROLLER_FIREWALLEXCEPTION -- indicates whether to create a rule for the Controller's port in the firewall. Possible values: true/false. Default: true;
      • LEAPWORK_ASSETS_DIR -- a path to a folder where all assets will be stored. Possible values: string, any valid path. Default: C:\Program Files\LEAPWORK\Assets\;
      • LEAPWORK_STUDIO_SHORTCUT -- indicates whether to create shortcuts for the Studio on the desktop and in the Start menu. Possible values: true/false. Default: true;
      • LEAPWORK_LOGS_DIR -- a path to a folder where all application log will be written. Possible values: string, any valid path. Default: C:\Program Files\LEAPWORK\Logs\.

For more information about MSI installation please visit following links from Microsoft:

Command-Line Options

Standard Command-Line Options

Examples

Simple install:

  • Windows 8 and above, Windows Server 2012 and above:
    msiexec.exe /i "path\to\installer.msi" /qn /norestart
  • Windows 7 and Windows Server 2008 R2:
    msiexec.exe /i "path\to\installer.msi" /qn /forcerestart

Install with logs:

  • Windows 8 and above, Windows Server 2012 and above:
    msiexec.exe /i "path\to\installer.msi" /qn /norestart /l*v "path\to\log.txt"
  • Windows 7 and Windows Server 2008 R2:
    msiexec.exe /i "path\to\installer.msi" /qn /forcerestart /l*v "path\to\log.txt"

Install only the Agent and the Controller:

  • Windows 8 and above, Windows Server 2012 and above:
    msiexec.exe /i "path\to\installer.msi" /qn /norestart /l*v "path\to\log.txt" ADDLOCAL=AgentFeature,ControllerFeature
  • Windows 7 and Windows Server 2008 R2:
    msiexec.exe /i "path\to\installer.msi" /qn /forcerestart /l*v "path\to\log.txt" ADDLOCAL=AgentFeature,ControllerFeature

Install only the Studio:

  • Windows 8 and above, Windows Server 2012 and above:
    msiexec.exe /i "path\to\installer.msi" /qn /norestart /l*v "path\to\log.txt" ADDLOCAL=StudioFeature
  • Windows 7 and Windows Server 2008 R2:
    msiexec.exe /i "path\to\installer.msi" /qn /forcerestart /l*v "path\to\log.txt" ADDLOCAL=StudioFeature

Install with custom parameters:

  • Windows 8 and above, Windows Server 2012 and above:
    msiexec.exe /i "path\to\installer.msi" /qn /norestart /l*v "path\to\log.txt" LEAPWORK_AGENT_PORT=5432 LEAPWORK_LOGS_DIR="C:\some folder\some subfolder\log.txt"
  • Windows 7 and Windows Server 2008 R2:
    msiexec.exe /i "path\to\installer.msi" /qn /forcerestart /l*v "path\to\log.txt"  LEAPWORK_AGENT_PORT=5432 LEAPWORK_LOGS_DIR="C:\some folder\some subfolder\log.txt"

Uninstall command in CMD:

  • Windows 8 and above, Windows Server 2012 and above:
    msiexec.exe /x "path\to\installer.msi" /qn /norestart
  • Windows 7 and Windows Server 2008 R2:
    msiexec.exe /x "path\to\installer.msi" /qn /forcerestart

Please note: Windows 7 and Windows server 2008 requires restart after installation which can be done manually or by adding a restart command in your command line script.

For any clarification, please contact our Priority Support
